Tilton’s 5100-Series hydraulic release bearing (also known as a hydraulic throwout bearing) features a flat-face contact bearing. Ideal for 8.5″ – 11.0″ bent finger clutches, the 5100-Series hydraulic release bearing is optimal for direct mounting inside the Bellhousing
Mount: 4-bolt pattern
Weight: 1.45 lbs
Application: 8.5″ – 11.0″ bent finger clutches
Overall height: 1.81” (46mm)
Contact: 1.71″ – 3.03″ (43.4mm – 77.0mm)
Bearing type: Flat-face
Body and piston material: Aluminum
Piston area: 1.215 in2 (784mm2)
Maximum stroke: .700″ (17.8mm)
Ports: AN-3 (3/8″-24)
Included in kit: AN-3 fittings (2)
Typical applications: Bulkhead-mounted inside transmissions or bellhousings
