Tilton’s 5200-Series hydraulic release bearing (also known as a hydraulic throwout bearing) features a 44mm (1.75″) radius-face contact bearing diameter. Ideal for 5.5″ – 7.25″ clutches, the 5200-Series hydraulic release bearing is optimal for direct mounting inside the bellhousing.
Mount: 4-bolt pattern
Weight: 0.45kgs (varies by P/N)
Application: 5.5″ – 7.25″ clutches
Contact: 1.75″ (44mm)
Bearing type: Radius-face
Body and piston material: Aluminum
Piston area: 1.215 in2 (784mm2)
Maximum stroke: .700″ (17.8mm)
Ports: AN-3 (3/8″-24)
Included in kit: AN-3 fittings (2)
Typical applications: Bulkhead-mounted inside transmissions or bellhousings
