Tilton’s 6000-Series hydraulic release bearings (also known as hydraulic throwout bearings or concentric slave cylinders) feature race-proven Tilton reliability for the street. These hydraulic release bearings have been designed for ease of installation and maximum reliability, at a very competitive price. 6000-Series hydraulic release bearings are designed to mount onto the transmission input shaft bearing retainer, and are compatible with a variety of transmission types:
- Ford Tremec TKO/TKX/500/600
- Ford T-5
- Toploader (1 1/16″ x 10 input shaft)
- Tremec T56/Magnum (Except for Tremec P/N TUET11010)
- Ford Tremec Magnum (P/N TUET11010)
- GM Tremec TKO/500/600
- GM Saginaw
- GM T-5
- and more.
| Application | Transmission | Height Adjustment (inches) |
Part Number |
|---|---|---|---|
| Chevy SB/BB | Tremec TKO/500/600 | 2.75 - 3.00** | 60-6036 |
| Chevy LS/LT | Tremec TKO/500/600 | 2.02 - 3.25* | 60-6031 |
| Chevy | Tremec T56 Magnum | 2.41 - 3.38** | 60-6035 |
| Chevy | Tremec TR6060 | 2.91 - 3.88** | 60-6041 |
| Chevy | Borg-Warner/Tremec T5 | 2.02 - 3.25* | 60-6033 |
| Ford | Tremec TKO/500/600 | 2.02 - 3.25* | 60-6032 |
| Ford | Tremec T56 Magnum (Pilot tube mount) | 2.02 - 3.25* | 60-6034 |
| Ford | Tremec T56 Magnum (2-bolt plate mount) | 2.54 - 3.51** | 60-6035 |
| Ford | Top Loader (1 1/16 x 10 spline) | 2.02 - 3.25* | 60-6032 |
| Ford | Borg-Warner /Tremec T5 | 2.02 - 3.25* | 60-6034 |
*Height adjustment on included sleeve that fits onto tube of input shaft bearing retainer. Does not include height of retainer base.
** Height adjustment on included mounting base. Dimension is form mating face of transmission to top of bearing.
